Garg Steels, a prominent manufacturer and supplier located in Chennai, India, is dedicated to providing high-precision Stainless Steel 440C Hex Bars tailored for demanding industrial needs. These hex bars are celebrated for their impressive strength, hardness, and wear resistance, making them perfect for the toughest performance challenges. With a strong focus on quality control and compliance with global standards, Garg Steels offers customized sizes and finishes suitable for tooling, automotive, and machinery applications. Known for their exceptional dimensional accuracy and commitment to timely delivery, Garg Steels has become a reliable partner for clients in search of durable, high-performance stainless steel hexagonal bars.
Stainless Steel 440C Hex Bar is a high-carbon martensitic stainless steel that contains around 0.95–1.2% carbon, 16–18% chromium, along with trace amounts of manganese and molybdenum. It’s recognized for its ability to be hardened to 58–60 HRC, providing outstanding tensile strength (up to 760 MPa) and wear resistance. While its corrosion resistance is moderate, it performs well in mildly corrosive environments when polished or passivated. The hexagonal shape not only enhances grip but also boosts machining efficiency, making 440C an excellent choice for components that require both strength and precision in high-stress situations.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 440C | 1.20-0.95 | 18.00-16.00 | 1.00 | 1.00 | 0.04 | 0.03-0.15 | 1.00 |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 440C | 1.20-0.95 | 18.00-16.00 | 1.00 | 1.00 | 0.04 | 0.03-0.15 | 1.00 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 440C Hex Bars find extensive use in scenarios where high hardness, strength, and wear resistance are crucial. Common applications include valve components, bearings, surgical instruments, shafts, dies, and cutting tools. The hexagonal design is particularly advantageous for precision machining and tight tolerance parts across aerospace, defense, automotive, and tooling sectors. These bars are also ideal for mechanical assemblies that require effective torque transfer. Thanks to 440C’s ability to maintain a sharp edge and resist wear under mechanical stress, they ensure long-lasting performance in both dynamic and static high-load environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
