Garg Steels, a reputable manufacturer and supplier located in Chennai, India, is known for its top-notch Titanium Grade 2 Forgings. These forgings are celebrated for their impressive strength-to-weight ratio, remarkable resistance to corrosion, and excellent weldability. Titanium Grade 2 is one of the most commonly used grades of commercially pure titanium, striking a perfect balance between moderate strength and ductility. Garg Steels offers forgings in tailored dimensions and configurations to cater to the rigorous demands of industries such as aerospace, marine, chemical processing, and medical equipment. Each product is crafted under stringent quality standards to guarantee durability and structural integrity in critical applications.
Titanium Grade 2 Forgings consist of 99.2% titanium, with only trace amounts of oxygen (up to 0.25%), iron, nitrogen, hydrogen, and carbon. This unique composition provides outstanding corrosion resistance, particularly in oxidizing and mildly reducing environments. With a tensile strength ranging from approximately 344 to 550 MPa, a yield strength of around 275 MPa, and an elongation of 20% or more, this material is perfect for applications that demand both strength and formability. It also retains excellent mechanical properties at both room and elevated temperatures, boasting a low density of 4.51 g/cm³, making it ideal for lightweight yet robust components.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| ASTM B381 R50400 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
The durability of Titanium Gr 2 forgings is ensured by factors like high corrosion resistance, excellent strength-to-weight ratio, superior fatigue resistance, heat treatment, proper alloy composition, and precision manufacturing processes.
Titanium Gr 2 forgings are commonly used in aerospace, chemical processing, marine, medical, automotive, and power generation industries due to their corrosion resistance, strength, and lightweight properties.
Open-die forging for Titanium Gr 2 components involves shaping the metal by pressing it between two flat dies. It allows for high strength, uniformity, and precise control, making it ideal for complex, large components.
Titanium Grade 2 Forgings find extensive use in industries that require exceptional corrosion resistance and moderate mechanical strength. They are perfect for marine components, chemical processing equipment, power generation condensers, heat exchangers, and desalination systems. Thanks to their non-toxic and biocompatible properties, they are also well-suited for medical devices and surgical implants. In the aerospace sector, Grade 2 is utilized in airframe and engine components where lightweight construction and corrosion resistance are essential. Garg Steels delivers Titanium Grade 2 Forgings customized to meet a variety of industrial needs, ensuring reliable performance and longevity.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Garg Steels is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Chennai, India
