Garg Steels, a well-respected manufacturer and supplier located in Chennai, India, specializes in high-quality Titanium Grade 7 Forgings that are celebrated for their outstanding corrosion resistance and durability. This particular titanium alloy, known as Titanium Gr 7, is nearly pure titanium with a touch of palladium added, which boosts its ability to resist corrosion, especially in harsh acidic and chloride-heavy environments. Garg Steels meticulously crafts these forgings to meet precise tolerances, making them ideal for critical applications in the chemical processing, marine, and power generation industries. With a strong focus on quality, innovation, and customer satisfaction, Garg Steels guarantees that their Titanium Gr 7 forgings deliver reliable performance and longevity, even in the toughest industrial conditions.
Titanium Grade 7 Forgings are made from commercially pure titanium (Ti) with a small percentage of palladium (0.12%–0.25%), which greatly improves their corrosion resistance. This alloy boasts a tensile strength ranging from about 344 to 483 MPa, a yield strength of around 275 MPa, and impressive ductility with an elongation exceeding 20%. It maintains its strength and stability in both oxidizing and reducing environments and shows remarkable resistance to crevice corrosion. With a density of 4.51 g/cm³, Titanium Gr 7 strikes a perfect balance between formability, strength, and corrosion resistance, making it ideal for challenging chemical settings.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 7 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | .12 – .25 |
| 0.2% Proof Stress MPa | Tensile Strength MPa | Elongation % |
| 275-475 | 345 | 20 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 7 | 3.7235 | R52400 |
Titanium Grade 7 Forgings find their place in various industries where exceptional corrosion resistance is a must. They are commonly used in chemical processing plants, desalination systems, marine components, pulp and paper manufacturing, and power generation equipment. This alloy is particularly well-suited for applications that involve strong acids, chlorides, or contaminated seawater due to its superior resistance to localized corrosion. Its reliability and minimal maintenance needs make it perfect for heat exchangers, reactor vessels, piping systems, and valves. Garg Steels provides Titanium Gr 7 Forgings tailored to specific requirements, ensuring durability and high performance in demanding environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
